LGMG Off-Highway Dump Truck 2022 – Oil Radiator installation assy – A0300-2703012291
Category: 2022 > Off-Highway Dump Truck > CMT96 > C0960WF56
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Strap | 27030107251 | 2 |
| 2 | Plate | 27050106212 | 2 |
| 3 | Backing plate | 27020101971 | 2 |
| 4 | Bolt GB5783-M16*50-10.9 | 4011010364 | 1 |
| 5 | Nut GB6170-M16EpZn-10 | 4013000205 | 2 |
| 6 | Bolt GB5783-M16*60EpZn-10.9 | 4011010205 | 1 |
| 7 | Support | 27030122881 | 1 |
| 8 | Oil cooler | 4110001236 | 1 |
| 9 | Support | 27030122871 | 1 |
| 10 | Nut GB6170-M10EpZn-8 | 4013000007 | 8 |
| 11 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 12 | Cushion belt | 27030111821 | 2 |
