LGMG Off-Highway Dump Truck 2022 – Preheat electrical system – K3501-2735010003.S1A
Category: 2022 > Off-Highway Dump Truck > MT50 > M0500WE12
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Contactor JCC200/1C24.48A | 4130000628 | 1 |
| 2 | Hood | 27350100041 | 1 |
| 3 | Screw GB818-M5*35EpZn-4.8 | 4014010011 | 2 |
| 4 | Washer GB96.1-5EpZn-300HV | 4015000205 | 4 |
| 5 | No longer used | 4013000118 | 2 |
| 6 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 2 |
| 7 | Intake preheat controller | 4130000293 | 1 |
| 8 | Wire p15*1600 | 27200101891 | 1 |
| 9 | Preheat power line p15*1100 | 27200103701 | 1 |
| 10 | Bolt GB5783-M8*35EpZn-8.8 | 4011000195 | 2 |
| 11 | Nut GB6170-M6EpZn-8 | 4013000028 | 2 |
| 12 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 13 | Washer GB97.1-6EpZn-300HV | 4015000207 | 4 |
| 14 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
