LGMG Off-Highway Dump Truck 2022 – Preheat electrical system – K3501-2735010101.S1A
Category: 2022 > Off-Highway Dump Truck > MT86H- > M086HW3A0M012
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Wire p15*5000 | 27350100971 | 1 |
| 2 | Wire | 27350100221 | 1 |
| 3 | Washer GB96.1-8EpZn-300HV | 4015000256 | 1 |
| 4 | Bolt GB5783-M8*16EpZn-8.8 | 4011000102 | 1 |
| 5 | Bolt GB5783-M5*16EpZn-8.8 | 4011010096 | 2 |
| 6 | Nut GB6170-M5EpZn-8 | 4013010029 | 2 |
| 7 | Washer GB97.1-5EpZn-300HV | 4015000110 | 2 |
| 8 | Preheating relay HHZ H20-2-24R | 4130704101 | 1 |
| 9 | Wire | 27350100961 | 1 |
