LGMG Off-Highway Dump Truck 2022 – Rear leaf spring assy – G1201-4110000811
Category: 2022 > Off-Highway Dump Truck > MT50 > M0500WE12
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | 13th leaf of rear leaf spring | 4110000811013 | 1 |
| 2 | Center bolt of rear leaf spring | 4110000811014 | 1 |
| 3 | Center nut of rear leaf spring | 4110000811015 | 1 |
| 4 | Leaf of rear leaf spring | 4110000811001 | 4 |
| 5 | 5th leaf of rear leaf spring | 4110000811005 | 1 |
| 6 | 6th leaf of rear leaf spring | 4110000811006 | 1 |
| 7 | 7th leaf of rear leaf spring | 4110000811007 | 1 |
| 8 | 8th leaf of rear leaf spring | 4110000811008 | 1 |
| 9 | 9th leaf of rear leaf spring | 4110000811009 | 1 |
| 10 | 10th leaf of rear leaf spring | 4110000811010 | 1 |
| 11 | 11th leaf of rear leaf spring | 4110000811011 | 1 |
| 12 | 12th leaf of rear leaf spring | 4110000811012 | 1 |
