LGMG Off-Highway Dump Truck 2022 – RH side safety support installation assy – I0400-2740010880
Category: 2022 > Off-Highway Dump Truck > – > M096DW3A0M007
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | WASHER GB97.1-34EpZn-300HV | 4015010301 | 1 |
| 2 | Bolt GB5786-M16*1.5*55EpZn-8.8 | 4011000698 | 2 |
| 3 | Plate | 27400102561 | 1 |
| 4 | Pipe | 27400105921 | 1 |
| 5 | Assembly | 27170117352 | 1 |
| 6 | Fastening bolt damping block | 27170140901 | 2 |
| 7 | Bolt GB5785-M16*1.5*65EpZn-8.8 | 4011000981 | 4 |
| 8 | Nut GB6185.2-M16*1.5EpZn-8 | 4013010168 | 6 |
| 9 | Washer GB97.1-16EpZn-300HV | 4015000181 | 12 |
| 10 | Hose assembly | 27400103401 | 1 |
| 11 | Pin GB91-6.3*50EpZn-Q235A | 4016000040 | 1 |
