LGMG Off-Highway Dump Truck 2022 – Suspension assy – G1200-2712012430
Category: 2022 > Off-Highway Dump Truck > CMT66 > C0660W3E0A006
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Shock absorber assembly1 | 27120117281 | 1 |
| 2 | Front thrust rod install assembly | 27120117291 | 1 |
| 3 | Front suspension assembly | 27120124311 | 1 |
| 4 | Rear leaf spring assembly | 27120117311 | 1 |
| 5 | Rear the thrusting rod mounting assembly | 27120117321 | 1 |
