LGMG Off-Highway Dump Truck 2023 – 24V battery holder assy – L3601-2736017459.S1A
Category: 2023 > Off-Highway Dump Truck > RT136 > R1000W3A2M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6185.1-M10EpZn-10 | 4013010133 | 2 |
| 2 | Bolt GB5783-M10*90EpZn-12.9 | 4011011013 | 2 |
| 3 | Nut GB6185.1-M10EpZn-12 | 4013010567 | 2 |
| 4 | Plate | 27140154761 | 1 |
| 5 | Bolt GB16674.1-M10*30EpZn-8.8 | 4011000475 | 2 |
| 6 | Plate | 27140154741 | 1 |
| 7 | Bolt GB5783-M6*16EpZn-8.8 | 4011000289 | 8 |
| 8 | Battery box cover wldmt | 27360174681 | 1 |
| 9 | Rr cover plate 620*616*1.5 | 27360174661 | 1 |
| 10 | Fr cover plate 620*616*1.5 | 27360174671 | 1 |
| 11 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 29 |
| 12 | Washer GB96.1-6EpZn-300HV | 4015000198 | 65 |
| 13 | Nut GB6185.1-M6EpZn-8 | 4013010117 | 25 |
| 14 | 24v battery holder bracket wldmt | 27360174601 | 1 |
| 15 | Bolt GB5783-M10*65flZnyc-10.9-480 | 4011011565 | 2 |
| 16 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
