LGMG Off-Highway Dump Truck 2023 – Air conditioning assembly – N2101-2721010739
Category: 2023 > Off-Highway Dump Truck > MT50 > M0500WE86
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-6EpZn-300HV | 4015000207 | 8 |
| 2 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 3 | Washer GB96.1-10EpZn-300HV | 4015000197 | 4 |
| 4 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 4 |
| 5 | Clamp | 4190002236 | 1 |
| 6 | Nut GB6170-M6EpZn-8 | 4013000028 | 3 |
| 7 | Sheath | 27210103441 | 2 |
| 8 | Bracket | 4190002389 | 1 |
| 9 | Clamp | 4190002390 | 1 |
| 10 | Clamp | 4190002391 | 1 |
| 11 | Pipe（Evaporator-compressor）GK33-5.0K16-80-WX | 4130703626 | 1 |
| 12 | Bolt GB5783-M6*30EpZn-8.8 | 4011000291 | 8 |
| 13 | Washer GB93-6EpZn-65Mn | 4015000213 | 2 |
| 14 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 15 | Circal | 27210104261 | 1 |
| 16 | Valve assembly | 27210103841 | 1 |
| 17 | Intlet pipe of heater | 27210103824 | 1 |
| 18 | Double nipple clamp | 27210101701 | 2 |
| 19 | Washer GB96.1-6EpZn-300HV | 4015000198 | 2 |
| 20 | Pipe（Condenser-evaporator）GK33-5.0K16-60-WX | 4130703624 | 1 |
| 21 | Plate | 27210104271 | 1 |
| 22 | Hose clamp JB8870-D32 | 4017000011 | 6 |
| 23 | Shield | 4190002561 | 1 |
| 24 | Condenser assy | 4190708206 | 1 |
| 25 | Pipe（Compressor-condenser）GK33-5.0K16-70-WX | 4130703625 | 1 |
| 26 | Steering assembly | 27210104281 | 1 |
| 27 | Screw GB70.1-M10*1.25*30EpZn-12.9 | 4011010456 | 1 |
