LGMG Off-Highway Dump Truck 2023 – ASM-Lift Pump Assembly – M1600-2716013367
Category: 2023 > Off-Highway Dump Truck > RTH136(EQ) > R1260Y3A0A503
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Gear pump-CB-DP120-A | 4120710499 | 1 |
| 2 | Joint GE28LR11/4EDOMD | 4190001242 | 1 |
| 3 | Bracket | 27160131201 | 1 |
| 4 | Bolt GB5783-M12*45EpZn-8.8 | 4011000207 | 4 |
| 5 | Bolt GB5782-M8*65EpZn-8.8 | 4011000301 | 1 |
| 6 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 1 |
| 7 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 4 |
| 8 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 9 | JOINT LGB143-03625 | 4041001211 | 1 |
| 10 | Low pressure joint G1 1/4-φ46 | 4120001011 | 1 |
| 11 | Pump coupling | 4120001055 | 1 |
