LGMG Off-Highway Dump Truck 2023 – Asm-pipe – H1501-2715013055.S1A
Category: 2023 > Off-Highway Dump Truck > MT106H > M106HW3A0A101
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket | 27150127851 | 2 |
| 2 | Cable tie HS-J117 | 4130704969 | 1 |
| 3 | Hold-down block | 27150106471 | 4 |
| 4 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 1 |
| 5 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 6 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 7 | Bolt GB5783-M10*50EpZn-8.8 | 4011000489 | 3 |
| 8 | Washer GB96.1-10EpZn-300HV | 4015000197 | 2 |
| 9 | Weld-pipe | 27150128071 | 1 |
| 10 | Bolt GB5782-M6*30-8.8 | 4011000712 | 1 |
| 11 | Bulkhead joint M22 | 27150116651 | 2 |
| 12 | Washer GB96.1-6flZnyc-300HV-480 | 4015010296 | 2 |
| 13 | Nut GB6170-M6EpZn-8 | 4013000028 | 1 |
| 14 | Clapboard joint m26 | 27150116661 | 1 |
| 15 | Nut | 27150103221 | 1 |
| 16 | Tee CC-26 | 4190002536 | 1 |
| 17 | Combination joint LGB143-12616 | 4041001417 | 1 |
| 18 | Reducing joint RED18/08LOMDCF | 4120001300 | 1 |
| 19 | Weld-pipe | 27150128051 | 1 |
| 20 | Combination joint LGB143-12213 | 4041001218 | 2 |
| 21 | NUT | 27150102951 | 2 |
