LGMG Off-Highway Dump Truck 2023 – Battery box assembly – J1001-2710012335.S1A
Category: 2023 > Off-Highway Dump Truck > MT126H > C126HW3A0M002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Threading sheath | 4120000222 | 2 |
| 2 | Battery box bracket 48-DPX-03 | 4120711730 | 2 |
| 3 | Rubber hook | 4110000028 | 2 |
| 4 | Pin GB882-B4*50EpZn-35 | 4016010103 | 2 |
| 5 | Pin GB91-1*10EpZn-Q235A | 4016000096 | 2 |
| 6 | Battery box cover 48-DPX-04 | 4120711731 | 1 |
| 7 | Nut GB6177.1-M8EpZn-8 | 4013010186 | 6 |
| 8 | Fastening channel steel 48-DPX-06 | 4120711733 | 2 |
| 9 | Tighten support backing plate 48-DPX-07 | 4120711734 | 2 |
| 10 | The bolt damping block | 27100105471 | 12 |
| 11 | Rubber plate in middle | 27100105491 | 1 |
| 12 | U-Bolt 48-DPX-05 | 4120711732 | 3 |
| 13 | tube plate | 27100105481 | 1 |
| 14 | Battery box bottom 48-DPX-02 | 4120711729 | 1 |
