LGMG Off-Highway Dump Truck 2023 – Beam assembly – G1201-2712017455.S1B
Category: 2023 > Off-Highway Dump Truck > MT106H > M106HW3A0M354
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27120169921 | 4 |
| 2 | adjusting shim | 27120118401 | 4 |
| 3 | sdjusting shim | 27120118411 | 4 |
| 4 | Crossbeam weldment assembly | 27120175742 | 1 |
| 5 | Adjusting shim 1 | 27120174851 | 2 |
| 6 | Adjusting shim 0.5 | 27120174841 | 2 |
| 7 | Two beam seat weldent | 27120174721 | 2 |
| 8 | Bolt GB5782-M16*80flZnyc-12.9-480 | 4011010614 | 22 |
| 9 | Washer GB97.1-16EpZn-300HV | 4015000181 | 80 |
| 10 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 40 |
| 11 | Bolt GB5782-M16*60flZnyc-12.9-480 | 4011010623 | 18 |
| 12 | Two beam seat plate | 27120174771 | 2 |
