LGMG Off-Highway Dump Truck 2023 – Drive Shaft – F0700-4110706890
Category: 2023 > Off-Highway Dump Truck > MT126H > C126HW3A0M004
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Grease nipple M6 GB1152 | 4110703033009 | 2 |
| 2 | Connecting fork 5720-2205062 | 4110703233001 | 1 |
| 3 | Snap ring 5720-2205063 | 4110703233002 | 4 |
| 4 | Cardan assy 5720-2205080 | 4110703233003 | 1 |
| 5 | Universal joint fork 5720-2205096-A | 4110706890002 | 1 |
| 6 | Shaft tube ？140 * 6 * 486 | 4110706890001 | 1 |
| 7 | Spline shaft 5680-2204116-02 | 4110706880003 | 1 |
| 8 | Support assy 5680-2204030-T | 4110706880004 | 1 |
| 9 | Splines connecting disk5680-2204051-02Q1 | 4110702316002 | 1 |
| 10 | Nut 5680-2204052-A | 4110703033011 | 1 |
