LGMG Off-Highway Dump Truck 2023 – Elevator assembly – L3601-2736015918.S1A
Category: 2023 > Off-Highway Dump Truck > MT126H > C126HW3A0M003
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 8 |
| 2 | Canvas belt 360*72*20 | 27360159291 | 2 |
| 3 | Flexible ladder mounting plate 680*284*55 | 27360159571 | 1 |
| 4 | Flexible ladder mounting plate 680*284*55 | 27360159561 | 1 |
| 5 | Plate | 27360134851 | 3 |
| 6 | Plate | 27360121691 | 2 |
| 7 | Plate | 27360101631 | 4 |
| 8 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 4 |
| 9 | Washer GB97.1-10EpZn-300HV | 4015000162 | 12 |
| 10 | Nut GB6170-M10EpZn-8 | 4013000007 | 12 |
