LGMG Off-Highway Dump Truck 2023 – Exhaust assembly – L5400-2754000217
Category: 2023 > Off-Highway Dump Truck > RTH136(EQ) > R1260Y3A0A504
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27170177262 | 4 |
| 2 | Plate | 27170157931 | 16 |
| 3 | Plate | 27170157921 | 8 |
| 4 | Pin GB91-6.3*63EpZn-Q235A | 4016000113 | 4 |
| 5 | Nut GB6178-M36EpZn-10 | 4013010114 | 4 |
| 6 | Stone support | 27540002182 | 4 |
| 7 | Plate | 27170261541 | 4 |
| 8 | Bolt GB5783-M16*55EpZn-8.8 | 4011000612 | 16 |
| 9 | Nut GB6170-M16EpZn-8 | 4013000016 | 16 |
| 10 | Plate | 27170177252 | 4 |
| 11 | Plate | 27540000641 | 4 |
| 12 | Washer GB97.1-16EpZn-300HV | 4015000181 | 40 |
| 13 | Bolt GB5783-M16*30EpZn-8.8 | 4011000094 | 8 |
