LGMG Off-Highway Dump Truck 2023 – Frame assy – I1400-2714012879
Category: 2023 > Off-Highway Dump Truck > MS40 > MS400W2E0M009
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Middle seat | 27140124731 | 2 |
| 2 | Bolt GB5786-M16*1.5*60-12.9 | 4011010219 | 20 |
| 3 | NUT GB6185-M18*1.5EpZn-12 | 4013010252 | 72 |
| 4 | Washer GB1230-18EpZn-45 | 4015010219 | 48 |
| 5 | Bolt GB5785-M18*1.5*80-12.9 | 4011010700 | 12 |
| 6 | Trimmed gasket | 27140124532 | 2 |
| 7 | Trimmed gasket | 27140124522 | 2 |
| 8 | Bolt GB5786-M18*1.5*55-12.9 | 4011010739 | 60 |
| 9 | Beam assembly | 27140113101 | 2 |
| 10 | Balance shaft reinforce beam assembly | 27140125641 | 1 |
| 11 | Left carling | 27140128801 | 1 |
| 12 | Tail carling assembly | 27140111651 | 1 |
| 13 | Nut GB6170-M10EpZn-8 | 4013000007 | 3 |
| 14 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 3 |
| 15 | RIVET GB867-14*42 | 4019000110 | 2 |
| 16 | Beam assembly | 27140125671 | 1 |
| 17 | Left reinforce carling | 27140128811 | 1 |
| 18 | Right reinforce carling | 27140128821 | 1 |
| 19 | Right carling | 27140128831 | 1 |
| 20 | Nut GB6185.2-M16*1.5-12 | 4013010222 | 85 |
| 21 | BOLT GB5786-M16*1.5*50-12.9 | 4011010738 | 65 |
| 22 | Rivet GB867-14*52 | 4019000115 | 22 |
| 23 | Rivet GB867-14*65 | 4019000120 | 44 |
| 24 | Side plate | 27140121682 | 2 |
