LGMG Off-Highway Dump Truck 2023 – Frame assy – I1401-2714019604.S1A
Category: 2023 > Off-Highway Dump Truck > CMT96H > C096HW3E0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | BOLT GB5785-M16*1.5*75EpZn-8.8 | 4011010461 | 2 |
| 2 | Nut GB6185.2-M16*1.5EpZn-8 | 4013010168 | 2 |
| 3 | Bolt GB5786-M16*1.5*50flZnyc-12.9-480 | 4011010555 | 12 |
| 4 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 32 |
| 5 | Bolt GB5786-M16*1.5*45EpZn-8.8 | 4011000494 | 2 |
| 6 | Bolt GB5785-M16*1.5*80flZnyc-12.9-480 | 4011010592 | 16 |
| 7 | Washer GB1230-16EpZn-45 | 4015000001 | 16 |
| 8 | Bolt GB5786-M16*1.5*60-12.9 | 4011010219 | 10 |
| 9 | Nut GB6185.2-M16*1.5-12 | 4013010222 | 10 |
| 10 | Platform bracket installation | 27140196211 | 1 |
| 11 | Front guard | 27140138951 | 1 |
| 12 | Rear traction seat | 27140104822 | 1 |
| 13 | Bolt GB5786-M16*1.5*60flZnyc-12.9-480 | 4011010585 | 4 |
| 14 | Pin | 27140105842 | 1 |
| 15 | Pin GB91-6.3*71EpZn-Q235A | 4016010125 | 1 |
| 16 | Frame | 27140196051 | 1 |
| 17 | Connecting rod | 27140123531 | 2 |
| 18 | Traction hook | 27140196141 | 2 |
| 19 | Frame | 27140173251 | 1 |
| 20 | Frame | 27140173281 | 1 |
| 21 | Frame | 27140173261 | 1 |
| 22 | Bolt GB5785-M16*1.5*80EpZn-8.8 | 4011010166 | 2 |
| 23 | Washer GB97.1-16EpZn-300HV | 4015000181 | 4 |
| 24 | Spacer 30*6.5*34 | 27140196201 | 2 |
