LGMG Off-Highway Dump Truck 2023 – Frame – I1401-2714018553.S1A
Category: 2023 > Off-Highway Dump Truck > MT126H > C126HW3A0M004
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Board | 27140185601 | 4 |
| 2 | Bolt GB5785-M18*1.5*80-12.9 | 4011010700 | 22 |
| 3 | NUT GB6185-M18*1.5EpZn-12 | 4013010252 | 22 |
| 4 | BOLT GB5785-M16*1.5*75-12.9 | 4011010391 | 32 |
| 5 | Nut GB6185.2-M16*1.5-12 | 4013010222 | 185 |
| 6 | Bolt GB5785-M16*1.5*80-12.9 | 4011010792 | 129 |
| 7 | Beam assembly | 27140185721 | 1 |
| 8 | Bolt GB5783-M10*50EpZn-8.8 | 4011000489 | 4 |
| 9 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 10 | Bolt GB5785-M16*1.5*55EpZn-10.9 | 4011010285 | 6 |
| 11 | Beam | 27140185542 | 1 |
| 12 | Nut GB6185.2-M16*1.5EpZn-10 | 4013010171 | 6 |
| 13 | Bolt GB5785-M18*1.5*70flZnyc-12.9-480 | 4011010497 | 4 |
| 14 | Nut GB6185.2-M18*1.5flZnyc-12-480 | 4013010239 | 4 |
| 15 | Bolt GB5785-M16*1.5*65flZnyc-12.9-480 | 4011010698 | 22 |
| 16 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 14 |
| 17 | Bolt GB5785-M16*1.5*90-12.9 | 4011010471 | 16 |
| 18 | Front guard weldment | 27140186151 | 4 |
| 19 | Beam assembly | 27140185681 | 1 |
| 20 | Board | 27140186212 | 2 |
| 21 | Beam assembly | 27140185781 | 1 |
| 22 | Beam | 27140185552 | 1 |
| 23 | RIVET GB867-16*60 | 4019000137 | 19 |
| 24 | Beam | 27140185562 | 1 |
| 25 | Frame assembly | 27140185572 | 1 |
| 26 | Beam | 27140185582 | 1 |
| 27 | Beam | 27140185592 | 1 |
| 28 | Board | 27140185832 | 1 |
| 29 | Board | 27140186092 | 1 |
| 30 | Beam assembly | 27140185611 | 1 |
