LGMG Off-Highway Dump Truck 2023 – Fuel tank assy – A0203-2702010204-G2
Category: 2023 > Off-Highway Dump Truck > MT50 > M0500WE14
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pin GB91-3.2*22EpZn-Q235A | 4016000183 | 2 |
| 2 | Pin | 4110000907 | 2 |
| 3 | Fuel tank bracket assy | 4110000905 | 2 |
| 4 | Aluminium oil box cover | 4049010004 | 1 |
| 5 | Fuel sieve | 4110000046 | 1 |
| 6 | Pipe plate i | 27020102053 | 1 |
| 7 | Bolt GB16674.1-M12*45EpZn-8.8 | 4011000467 | 2 |
| 8 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 4 |
| 9 | Oil pipe ⅰ | 27020103142 | 1 |
| 10 | Strainer plate | 27010111371 | 1 |
| 11 | Fuel tank | 4110000904 | 1 |
| 12 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 2 |
| 13 | Fuel filter | 4110000134 | 1 |
| 14 | FUEL PIPE | 27020102061 | 1 |
| 15 | Bolt JB999-M14*1.5*32EpZn-35 | 4011000344 | 4 |
| 16 | Washer JB1002-14-T2 | 4030000057 | 8 |
| 17 | Fagging | 27140108681 | 1 |
| 18 | Cable tie assy | 4110000906 | 2 |
| 19 | Nut GB6170-M16EpZn-8 | 4013000016 | 4 |
| 20 | Cable tie belt | 4110000908 | 2 |
| 21 | Carrier pad belt | 4110000909 | 2 |
| 22 | Bolt GB5783-M16*65EpZn-8.8 | 4011000421 | 4 |
| 23 | Washer GB97.1-16EpZn-300HV | 4015000181 | 8 |
| 24 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 4 |
| 25 | Fixed plate | 27020101021 | 2 |
