LGMG Off-Highway Dump Truck 2023 – Left ladder assy – L3601-2736016435.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A409
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Hinge | 27360154891 | 2 |
| 2 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 16 |
| 3 | Nut GB6170-M10EpZn-8 | 4013000007 | 16 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 16 |
| 5 | Access ladder assembly | 27360165891 | 1 |
| 6 | Bolt GB5783-M12*35EpZn-8.8 | 4011000090 | 4 |
| 7 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 8 | Left ladder platform weldment | 27360164361 | 1 |
| 9 | Plate | 27360135591 | 2 |
| 10 | Plate 316*160*3 | 27360164161 | 1 |
| 11 | Lock frame 305*155*3 | 27360164131 | 1 |
| 12 | Cabinet lock | 27360154881 | 1 |
| 13 | Nut GB889.1-M6EpZn-8 | 4013000211 | 8 |
