LGMG Off-Highway Dump Truck 2023 – Module installation assembly – J1101-2711011344.S1A
Category: 2023 > Off-Highway Dump Truck > MT106H > M106HW3A0M329
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 4 |
| 2 | Air reservoir 30L（275） | 4120000142 | 1 |
| 3 | Hose clamp φ275-φ280 | 4120000178 | 2 |
| 4 | Plug NG12-M22*1.5 | 4120000201 | 1 |
| 5 | Nut seat | 27110107601 | 2 |
| 6 | Drain valve | 4120000200 | 1 |
| 7 | Air reservoir bracket | 27110101222 | 1 |
| 8 | Plate assembly | 27110113452 | 1 |
| 9 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 2 |
| 10 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
