LGMG Off-Highway Dump Truck 2023 – Mudflap assy – L3601-2736017796.S1A
Category: 2023 > Off-Highway Dump Truck > RT100 > R1000W3A0M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 46 |
| 2 | Plate | 27360139191 | 6 |
| 3 | Front side mudguard | 27360167552 | 1 |
| 4 | Fr side mudflap | 27360177971 | 2 |
| 5 | Hold-down plate iv | 27360167862 | 2 |
| 6 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 16 |
| 7 | Washer GB97.1-8EpZn-300HV | 4015000072 | 16 |
| 8 | Mudguard | 27360167542 | 1 |
| 9 | Left rear mudflap installation | 27360168731 | 1 |
| 10 | Bolt GB5783-M12*25EpZn-8.8 | 4011000197 | 12 |
| 11 | Washer GB97.1-12EpZn-300HV | 4015000168 | 12 |
| 12 | Mud flap rr rh mounting assy | 27360141961 | 1 |
| 13 | Hold-down strip | 27360167691 | 2 |
| 14 | Plate | 27360139161 | 14 |
| 15 | Plate | 27360144111 | 2 |
| 16 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 46 |
| 17 | Washer GB96.1-8EpZn-300HV | 4015000256 | 76 |
