LGMG Off-Highway Dump Truck 2023 – Oil Radiator installation assy – A0301-2703011363
Category: 2023 > Off-Highway Dump Truck > MT86H > M086HW3A0A015
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27050106201 | 2 |
| 2 | Plate | 27050106212 | 2 |
| 3 | Strap | 27030107251 | 2 |
| 4 | Backing plate | 27020101971 | 2 |
| 5 | Nut GB6170-M16EpZn-10 | 4013000205 | 2 |
| 6 | Bolt GB5783-M16*50-10.9 | 4011010364 | 1 |
| 7 | Bolt GB5783-M16*60EpZn-10.9 | 4011010205 | 1 |
| 8 | BASED PLATE ASSEMBLY | 27030112861 | 1 |
| 9 | Oil cooler | 4110001236 | 1 |
| 10 | Plate | 27030112871 | 1 |
| 11 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 12 | Nut GB6170-M10EpZn-8 | 4013000007 | 8 |
