LGMG Off-Highway Dump Truck 2023 – Platform support assy – I1401-2714018832.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A404
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Connecting beam weldment | 27140188561 | 1 |
| 2 | Bolt QC340.2-M18*1.5*50EpZn-10.9 | 4011011598 | 32 |
| 3 | Nut GB6177.2-RLM18*1.5EpZn-10 | 4013010546 | 50 |
| 4 | Connecting plate 150*145*8 | 27140188871 | 2 |
| 5 | Plate 270*50*28 | 27140188881 | 2 |
| 6 | Bolt QC340.2-M18*1.5*80EpZn-10.9 | 4011011612 | 6 |
| 7 | Left middle platform suppport weldment | 27140188581 | 1 |
| 8 | Crossbeam weldment | 27140188531 | 1 |
| 9 | Plate | 27140185351 | 2 |
| 10 | Plate | 27140186601 | 2 |
| 11 | Front platform support weldment | 27140188331 | 1 |
| 12 | Right middle platform support weldment | 27140188821 | 1 |
| 13 | Cushion block | 27120113681 | 2 |
| 14 | Bolt QC340-M18*1.5*60EpZn-10.9 | 4011011616 | 12 |
| 15 | Right platform support weldment | 27140188511 | 1 |
| 16 | Connecting beam weldment | 27140188831 | 1 |
| 17 | Right rear platform support weldment | 27140188521 | 1 |
| 18 | Rear limiting mount weldment | 27140188891 | 1 |
| 19 | Bolt GB5783-M14*40EpZn-8.8 | 4011000814 | 4 |
| 20 | Nut GB6185.1-M14EpZn-8 | 4013010121 | 4 |
| 21 | Front right platform suppport weldment | 27140188711 | 1 |
| 22 | Limit plate weldment | 27140188861 | 4 |
| 23 | Bolt GB5786-M14*1.5*45EpZn-8.8 | 4011000876 | 16 |
| 24 | Washer GB97.1-14EpZn-300HV | 4015000177 | 16 |
| 25 | Nut GB6185.2-M14*1.5EpZn-8 | 4013010203 | 16 |
| 26 | Bolt GB5785-M16*1.5*65flZnyc-12.9-480 | 4011010698 | 16 |
| 27 | Washer GB1230-16EpZn-45 | 4015000001 | 16 |
| 28 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 16 |
