LGMG Off-Highway Dump Truck 2023 – Radiator assy – A0301-2703015144
Category: 2023 > Off-Highway Dump Truck > MT86H > M086HWG11
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pipe | 27030116891 | 1 |
| 2 | Butterfly spring clamp φ51-φ73 | 4190708162 | 2 |
| 3 | Support iii assembly | 27030106181 | 1 |
| 4 | Pipe | 27030106071 | 1 |
| 5 | Pipe | 27030112731 | 1 |
| 6 | Support ii assembly | 27030106151 | 1 |
| 7 | Pipe | 27030116901 | 1 |
| 8 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 4 |
| 9 | Washer GB96.1-6EpZn-300HV | 4015000198 | 9 |
| 10 | Pipe | 27030116881 | 1 |
| 11 | Pipe | 27030105993 | 1 |
| 12 | Support i | 27030106991 | 1 |
| 13 | Plate | 27030112781 | 1 |
| 14 | Plate | 27160104461 | 1 |
| 15 | BEAM | 27030112791 | 1 |
| 16 | Support ii | 27030107221 | 2 |
| 17 | Pipe | 27050106121 | 1 |
| 18 | BEAM | 27030112801 | 1 |
| 19 | Washer GB96.1-8EpZn-300HV | 4015000256 | 10 |
| 20 | Pipe | 27030116861 | 1 |
| 21 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 2 |
| 22 | Pipe | 27030105982 | 1 |
| 23 | Pipe 1 | 27030108303 | 1 |
| 24 | Bolt GB5783-M6*35EpZn-8.8 | 4011000286 | 2 |
| 25 | Clamp | 27030111951 | 1 |
| 26 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 4 |
| 27 | LEFT REINFORCE CARLING | 27030113651 | 1 |
| 28 | Bolt GB5782-M10*90EpZn-8.8 | 4011000053 | 2 |
| 29 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 9 |
| 30 | BOLT GB5783-M14*65flZnyc-12.9-480 | 4011010546 | 2 |
| 31 | Pipe clamp | 27030106201 | 1 |
| 32 | Bolt GB5783-M8*40EpZn-8.8 | 4011000299 | 1 |
| 33 | Pipe | 27030151431 | 1 |
| 34 | Adapter | 4110001033 | 1 |
| 35 | Washer GB97.1-6-300HV | 4015000230 | 1 |
| 36 | Bolt GB5783-M6*25EpZn-8.8 | 4011000276 | 2 |
| 37 | Nut GB6185.1-M6EpZn-8 | 4013010117 | 8 |
| 38 | Bolt GB5782-M12*55EpZn-8.8 | 4011000186 | 2 |
| 39 | Bolt GB5782-M14*50EpZn-8.8 | 4011000267 | 2 |
| 40 | Washer GB97.1-8-300HV | 4015000315 | 1 |
| 41 | Pipe clamp ii | 27030106211 | 2 |
| 42 | Pipe | 27030116911 | 1 |
| 43 | Pipe | 27030119521 | 1 |
| 44 | Cold air intake pipe | 27030105791 | 1 |
| 45 | Glass fiber Reinforced plastic wind guide cover | 4110001522 | 1 |
| 46 | Radiator assy | 4110001572 | 1 |
| 47 | Cooler assemble support | 27030109661 | 1 |
| 48 | Butterfly spring clamp φ57-φ79 | 4190708163 | 8 |
| 49 | Butterfly spring clamp φ93-φ118 | 4190708166 | 4 |
| 50 | Support i | 27030105861 | 1 |
| 51 | 90°Elbow CX31-1503602 | 4110001125 | 2 |
| 52 | Nut GB6185.1-M8EpZn-10 | 4013010132 | 3 |
| 53 | Bolt GB5783-M8*40flZnyc-12.9-480 | 4011010904 | 2 |
| 54 | Washer GB97.1-8EpZn-300HV | 4015000072 | 1 |
| 55 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 9 |
| 56 | Washer GB96.1-10EpZn-300HV | 4015000197 | 6 |
| 57 | Plate | 27030111161 | 1 |
| 58 | Plate | 27030106761 | 1 |
| 59 | Rubber plate | 27030133051 | 2 |
| 60 | Outlet pipe assy | 4110001327 | 1 |
| 61 | Oil inlet hose assy | 4110001326 | 1 |
| 62 | Pipe | 27030116871 | 1 |
| 63 | Bolt GB5782-M10*50EpZn-8.8 | 4011000048 | 1 |
| 64 | BEAM ASSEMB | 27030113631 | 1 |
| 65 | Pipe clamp LGB167-0846 | 4041010082 | 2 |
| 66 | Bolt GB5782-M8*55EpZn-8.8 | 4011000415 | 1 |
| 67 | CUSHION SLEEVE LGB123-0846 | 4041001636 | 2 |
| 68 | 45°Joint CX31-1503601 | 4110001126 | 2 |
| 69 | Butterfly spring clamp φ70-φ92 | 4190708164 | 6 |
| 70 | Expansion tank assembly | 27030151451 | 1 |
| 71 | Support ii | 27030105872 | 1 |
| 72 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 8 |
