LGMG Off-Highway Dump Truck 2023 – Reversing imaging system – K2700-2727010101
Category: 2023 > Off-Highway Dump Truck > MT86H > M086HWF21
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Extension cable 8P-2.8m | 4130704113 | 1 |
| 2 | Camera transmission wire 10m | 4130704121 | 1 |
| 3 | High definition display KLCR-706 | 4130704119 | 1 |
| 4 | Display support XSPZJ | 4130704120 | 1 |
| 5 | Bracket | 27270100912 | 1 |
| 6 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 2 |
| 7 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 8 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 9 | External camera KLCM-7 | 4130704115 | 1 |
| 10 | Rubber sleeve | 23270000311 | 1 |
| 11 | Screw GB818-M4*25EpZn-4.8 | 4014000008 | 2 |
| 12 | Nut GB6170-M4EpZn-8 | 4013000025 | 2 |
| 13 | Washer GB97.1-4EpZn-300HV | 4015000135 | 2 |
