LGMG Off-Highway Dump Truck 2023 – Seat assembly – G1201-2712017458.S1A
Category: 2023 > Off-Highway Dump Truck > MT116 > M116HY3A0M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Traction seat weldent | 27120174602 | 1 |
| 2 | Bolt GB5782-M16*90flZnyc-12.9-480 | 4011010646 | 10 |
| 3 | Washer GB1230-16EpZn-45 | 4015000001 | 10 |
| 4 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 10 |
