LGMG Off-Highway Dump Truck 2023 – Steering assembly – H6000-2760000130.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A406
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Straight joint 1CB-22-06WD | 4120005156 | 1 |
| 2 | Straight joint 1CB-16-04WD | 4120001369 | 2 |
| 3 | Base plate brkt power unit | 27600000751 | 1 |
| 4 | BOLT GB5783-M8*55EpZn-8.8 | 4011010609 | 2 |
| 5 | Washer GB97.1-8EpZn-300HV | 4015000072 | 2 |
| 6 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 7 | Plate | 27150112741 | 1 |
| 8 | Bolt GB5783-M10*50EpZn-8.8 | 4011000489 | 2 |
| 9 | Washer GB97.1-10EpZn-300HV | 4015000162 | 3 |
| 10 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 11 | Power unit | 4120702906 | 1 |
