LGMG Off-Highway Dump Truck 2024 – Battery box assy 49-DPX-02 – J0701-4190706949
Category: 2024 > Off-Highway Dump Truck > MT116H > M116HY3A0M038
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | The bolt damping block | 27100105471 | 12 |
| 2 | Nut GB6177.1-M8EpZn-8 | 4013010186 | 6 |
| 3 | U bolt | 27100105521 | 3 |
| 4 | Pin GB882-B4*50EpZn-35 | 4016010103 | 2 |
| 5 | Pin GB91-1*10EpZn-Q235A | 4016000096 | 2 |
| 6 | Current box bracket assembly（right） | 27100116631 | 1 |
| 7 | Current box bracket assembly（left） | 27100116651 | 1 |
| 8 | Battery box bottom 48-DPXD-01 | 4190706948 | 1 |
| 9 | Battery box cover | 4110000026 | 1 |
| 10 | Battery box bracket | 4110000027 | 2 |
| 11 | Rubber hook | 4110000028 | 2 |
| 12 | Bracket | 27100105511 | 2 |
| 13 | Threading sheath | 4120000222 | 1 |
| 14 | Rubber plate in middle | 27100105491 | 1 |
| 15 | tube plate | 27100105481 | 1 |
| 16 | Tighten supporting plate | 27100105501 | 2 |
