LGMG Off-Highway Dump Truck 2024 – Covering elec module – K2001-2720018607.S1B
Category: 2024 > Off-Highway Dump Truck > MTH116M > M116MY3A2AU003
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M5*16flZnyc-8.8-480 | 4011010958 | 8 |
| 2 | Bolt GB5783-M8*25flznyc-8.8-480 | 4011010743 | 2 |
| 3 | Nut GB6170-M5flZnyc-8-480 | 4013010298 | 8 |
| 4 | Nut GB6170-M8flznyc-8-480 | 4013010291 | 2 |
| 5 | Washer GB97.1-5flZnyc-300HV-480 | 4015010283 | 8 |
| 6 | Washer GB97.1-8flZnyc-300HV-480 | 4015010280 | 4 |
| 7 | LED FR work lamp SG-GZ050C | 4130704856 | 3 |
| 8 | LED FR steering lamp | 4130000252 | 2 |
| 9 | LED Fog lamp SM6053（three pin plug） | 4130000921 | 2 |
| 10 | SMG-011 Side marker lamp 3112040324 | 4130001148 | 3 |
| 11 | Side steering lamp 43-3001A | 4130000343 | 2 |
| 12 | FR headlamp（RH） | 4130000250 | 1 |
| 13 | FR headlamp（LH） | 4130000249 | 1 |
| 14 | Monophonic disc wooFer（treble） | 4130000907 | 1 |
| 15 | Monophonic disc woofer | 4130000906 | 1 |
