LGMG Off-Highway Dump Truck 2024 – Diesel heating assembly – A0301-2703015594
Category: 2024 > Off-Highway Dump Truck > CMT66A > C066AW3E0A002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Return oil pipe assy 685 φ56 G14H | 4110706509 | 1 |
| 2 | Diesel fuel heating intake pipe 35*5*3150 | 2703015600-001 | 1 |
| 3 | Diesel fuel heating return pipe 35*5*3100 | 2703015599-001 | 1 |
| 4 | Diesel heater power wire harness LG03-CNXS-001 | 4130706075 | 1 |
| 5 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 12 |
| 6 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 13 |
| 7 | Bolt GB16674.1-M10*40flZnyc-8.8-480 | 4011011086 | 1 |
| 8 | Plate | 27020109291 | 1 |
| 9 | Butterfly spring clamp φ25-φ45 | 4190708159 | 6 |
| 10 | Cable tie HS-J117 | 4130704969 | 1 |
| 11 | Nylon large tie strap HS-J118 | 4130705870 | 6 |
| 12 | Plate | 27010113352 | 5 |
| 13 | Pipe | 27030143691 | 2 |
| 14 | Bolt GB16674.1-M8*30EpZn-8.8 | 4011000481 | 1 |
| 15 | Bolt GB16674.1-M8*20EpZn-8.8 | 4011000458 | 1 |
| 16 | Diesel heating Intake pipe29.5*5*450 | 2703015546-002 | 1 |
| 17 | Diesel fuel heating bracket welding | 27030155951 | 1 |
| 18 | Chai nuan parking heater YJ-Q30/2ASL | 4110703687 | 1 |
| 19 | BOLT GB5785-M16*1.5*75-12.9 | 4011010391 | 6 |
