LGMG Off-Highway Dump Truck 2024 – Exhaust assembly – L5401-2754000187.S1B
Category: 2024 > Off-Highway Dump Truck > MT106H > M106HW3A0M415
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M16*30EpZn-8.8 | 4011000094 | 8 |
| 2 | Plate | 27170177955 | 4 |
| 3 | Plate | 27170177252 | 8 |
| 4 | Plate | 27170177262 | 4 |
| 5 | Middle row stone support | 27540001883 | 2 |
| 6 | Nut GB6177.2-RLM18*1.5EpZn-10 | 4013010546 | 8 |
| 7 | Bolt QC340-M18*1.5*60EpZn-10.9 | 4011011616 | 8 |
| 8 | Stone bar | 27540001901 | 4 |
| 9 | Rear stone support | 27540001893 | 2 |
| 10 | Pin GB91-6.3*63EpZn-Q235A | 4016000113 | 4 |
| 11 | Nut GB6178-M36EpZn-10 | 4013010114 | 4 |
| 12 | Limit plate | 27170226242 | 8 |
| 13 | Plate | 27170251351 | 2 |
| 14 | Bolt GB5782-M16*65EpZn-8.8 | 4011000459 | 8 |
| 15 | Washer GB97.1-16EpZn-300HV | 4015000181 | 24 |
| 16 | Nut GB6170-M16EpZn-8 | 4013000016 | 8 |
