LGMG Off-Highway Dump Truck 2024 – Fan shroud assy – I3901-2739010469.S1A
Category: 2024 > Off-Highway Dump Truck > CMT116H > C116HY3E0M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6170-M10EpZn-8 | 4013000007 | 10 |
| 2 | Bolt GB5782-M10*60EpZn-8.8 | 4011000050 | 4 |
| 3 | Connecting plate | 27390104701 | 2 |
| 4 | U SHAP BOLT | 27390100171 | 2 |
| 5 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 2 |
| 6 | Plate | 27390103201 | 1 |
| 7 | Rubber mat | 27390100201 | 2 |
| 8 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
