LGMG Off-Highway Dump Truck 2024 – frame – I1401-2714019805.S1A
Category: 2024 > Off-Highway Dump Truck > KT25 > M0250Y3E0M102
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Frame | 27140198061 | 1 |
| 2 | Fastening bolt damping block | 27170140901 | 1 |
| 3 | Frame | 27140198101 | 1 |
| 4 | Frame | 27140198191 | 1 |
| 5 | Bolt GB5786-M12*1.5*45EpZn-10.9 | 4011010268 | 1 |
| 6 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 7 | Nut GB6185.2-M12*1.5EpZn-10 | 4013010172 | 1 |
| 8 | Frame | 27140198071 | 1 |
| 9 | Bolt GB5785-M16*1.5*65EpZn-8.8 | 4011000981 | 3 |
| 10 | Washer GB97.1-16EpZn-300HV | 4015000181 | 6 |
| 11 | Nut GB6185.2-M16*1.5EpZn-8 | 4013010168 | 3 |
