LGMG Off-Highway Dump Truck 2024 – Oil suction manifold block assy – M1601-2716014232.S1B
Category: 2024 > Off-Highway Dump Truck > MTE106H > C106HE0A0A903
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | L-bracket 194*152*8 | 27160133992 | 1 |
| 2 | Welding | 27150120751 | 1 |
| 3 | Bolt GB5783-M10*25EpZn-10.9 | 4011000993 | 4 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 5 | Oil suction joint welding | 27160133131 | 1 |
| 6 | Oil suction valve | 27160133141 | 1 |
| 7 | Split flange LGB117-320760 | 4041000009 | 2 |
| 8 | O-ring GB3452.1-56.0*3.55G | 4030000133 | 2 |
| 9 | Oil suction pipe wldmt | 27160142331 | 1 |
| 10 | Screw GB70.1-M12*35EpZn-8.8 | 4014000110 | 8 |
| 11 | Washer GB97.1-12EpZn-300HV | 4015000168 | 8 |
| 12 | Split flange LGB117-310491 | 4041000026 | 1 |
| 13 | O-ring GB3452.1-30.0*3.55G | 4030000178 | 1 |
| 14 | Screw GB70.1-M10*30EpZn-8.8 | 4014000134 | 4 |
