LGMG Off-Highway Dump Truck 2024 – Rear axle installation – E0801-2708010587.S1A
Category: 2024 > Off-Highway Dump Truck > CMT66A > C066AW3E0A005
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27080103311 | 1 |
| 2 | 20T HD Rear axle assy（i=16.086） | 4110707777 | 1 |
| 3 | Sign | 27120120411 | 1 |
| 4 | Bolt m24*2*250 | 27070103911 | 8 |
| 5 | Plate | 27120120401 | 1 |
| 6 | PIN | 27070103491 | 4 |
| 7 | Plate | 27080103301 | 1 |
| 8 | Seat | 27120117371 | 1 |
| 9 | Locating pin | 27070101441 | 1 |
| 10 | Bolt m24*2*60 | 27070103901 | 8 |
