LGMG Off-Highway Dump Truck 2024 – Rearview camera sys – K2701-2727010136.S1D
Category: 2024 > Off-Highway Dump Truck > MTE106H > C106HE0A0A504
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Backup camera bracket wldmt | 27200176232 | 1 |
| 2 | Bolt GB5786-M16*1.5*60flZnyc-12.9-480 | 4011010585 | 2 |
| 3 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 4 |
| 4 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 2 |
| 5 | Wire 2.8m（8P） | 4130704113-001 | 1 |
| 6 | High definition display KLCR-706 | 4130704119 | 1 |
| 7 | Screw GB845-ST4.8*19-C-H | 4014010240 | 4 |
| 8 | Washer GB96.1-5EpZn-300HV | 4015000205 | 4 |
| 9 | Display support XSPZJ | 4130704120 | 1 |
| 10 | External camera KLCM-7 | 4130704115 | 1 |
| 11 | Screw GB818-M4*16EpZn-4.8 | 4014000087 | 2 |
| 12 | Washer GB97.1-4EpZn-300HV | 4015000135 | 4 |
| 13 | Nut GB6170-M4EpZn-8 | 4013000025 | 2 |
