LGMG Off-Highway Dump Truck 2024 – Side battery base assy – K2000-2736018672.S1A
Category: 2024 > Off-Highway Dump Truck > CMT106H > C106HE0A0A410
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | BOLT GB5785-M16*1.5*75-12.9 | 4011010391 | 48 |
| 2 | Adjusting shim 90*90*1 | 27200155581 | 16 |
| 3 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 32 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 64 |
| 5 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 32 |
| 6 | Middle longit beam weldment | 27200160051 | 2 |
| 7 | Battery box base weldment | 27200160021 | 4 |
| 8 | Shim 158*150*2 | 27200157441 | 4 |
| 9 | Shim 158*150*1 | 27200157451 | 4 |
| 10 | Battery FR base wldmt | 27200157321 | 2 |
| 11 | Fr longit beam assy | 27360186731 | 1 |
| 12 | Welding of the middle crossbeam of the towing frame | 27200150231 | 4 |
| 13 | Shim 200*155*1 | 27200157461 | 2 |
| 14 | Shim 200*155*2 | 27200157471 | 2 |
| 15 | Bolt GB5786-M16*1.5*55flZnyc-12.9-480 | 4011010640 | 28 |
| 16 | Washer GB97.1-16-300HV | 4015000314 | 97 |
| 17 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 76 |
| 18 | Plate | 27200150221 | 20 |
