LGMG Road Sprinkler 2026 – Chassis mid elec module – K2001-2720019765.S1A
Category: 2026 > Road Sprinkler > CMS50 > CS500Y3E0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Cargo tank | 27140133211 | 1 |
| 2 | Nut GB889.1-M8EpZn-8 | 4013000210 | 2 |
| 3 | Bolt GB16674.1-M8*20EpZn-8.8 | 4011000458 | 2 |
| 4 | Washer GB97.1-4EpZn-300HV | 4015000135 | 3 |
| 5 | Support | 27130114201 | 1 |
| 6 | Screw GB818-M4*16EpZn-4.8 | 4014000087 | 3 |
| 7 | Large circular warning beacon YQDQ-JS-03 | 4130704079 | 1 |
| 8 | Stop lamp switch YK209KLA | 4130000492 | 1 |
| 9 | Air pressure sensor YG2221SLN | 4130000990 | 2 |
| 10 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 2 |
| 11 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 12 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 13 | Itt plate | 27200107441 | 2 |
| 14 | String casing | 27140105021 | 6 |
| 15 | Parking pressure switch 0.55MPa | 4130000006 | 1 |
| 16 | Bolt GB16674.1-M8*16EpZn-8.8 | 4011000461 | 2 |
