LGMG RTH100 2025 – Condenser installation – J1001-2710014415.S1A
Category: 2025 > RTH100 > R1000Y3A0A225
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 4 |
| 2 | Nut GB6170-M8flznyc-8-480 | 4013010291 | 4 |
| 3 | Bent plate 195*184*8 | 27100144161 | 1 |
| 4 | Bolt GB5783-M10*35flZnyc-10.9-480 | 4011010783 | 2 |
| 5 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 2 |
| 6 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 2 |
| 7 | Straight joint LGB177-02222 | 4041010528 | 2 |
| 8 | O-ring LGB168-11924 | 4041000771 | 2 |
| 9 | Combination joint LGB143-02213 | 4041001156 | 1 |
| 10 | Condenser 35290040020 | 4120710291 | 1 |
| 11 | Bolt GB5782-M8*120flZnyc-8.8-480 | 4011010951 | 4 |
