SDLG G9190 G9220 Draw bar 28350000742 联接架
SDLG G9190 G9220 PLATE 28350001551 左盖板
SDLG G9190 G9220 LUBRICATING NIPPLE 4030000065 油杯JB7940.1-M10*1
SDLG G9190 G9220 BOLT 4011000447 螺栓GB16674-M10*20EpZn-8.8 GB16674-M10*20EpZn-8.8
SDLG G9190 G9220 ATTACHMENT BRACKET 28350001782 回转架
SDLG G9190 G9220 PLATE 28350001561 右盖板
SDLG G9190 G9220 WASHER 28350001021 小齿轮垫片
SDLG G9190 G9220 RETAINING RING 4015000046 挡圈GB894.1-50-65Mn GB894.1-50-65Mn
SDLG G9190 G9220 SPHERICAL PLAIN BEARING 4021000050 关节轴承GB9163-GE50ES-2RS GB9163-GE50ES-2RS
SDLG G9190 G9220 GEAR 28350001511 驱动齿轮
SDLG G9190 G9220 SPHERICAL PLAIN BEARING 4021000043 关节轴承GB9163-GE70ES-2RS GB9163-GE70ES-2RS
SDLG G9190 G9220 SWING PINION SHAFT 28350003661 回转臂
SDLG G9190 G9220 CYLINDER 4120004766 回转油缸80*35*279.5-507
SDLG G9190 G9220 LOCKING PLATE 28350001641 锁紧垫片
SDLG G9190 G9220 BOLT 4011000993 螺栓GB5783-M10*25EpZn-10.9
SDLG G9190 G9220 WASHER 4015000162 垫圈GB97.1-10EpZn-300HV
SDLG G9190 G9220 PIN 28350001631 销轴
SDLG G9190 G9220 SPHERICAL PLAIN BEARING 4021000248 关节轴承GB9163-GE35ES
SDLG G9190 G9220 CYLINDER 4120004771 铲土角变换油缸100*50*260.5-562
SDLG G9190 G9220 PIN 28350001601 销轴
SDLG G9190 G9220 PLATE 28350001491 导向套垫片
SDLG G9190 G9220 BOLT 4011000763 螺栓GB5783-M10*30EpZn-10.9
SDLG G9190 G9220 CLAMPING PLATE 28350001501 夹板
SDLG G9190 G9220 SCREW 4011001062 螺栓GB5783-M16*60EpZn-10.9
SDLG G9190 G9220 WASHER 4015000181 垫圈GB97.1-16EpZn-300HV GB97.1-16EpZn-300HV
SDLG G9190 G9220 GUIDE BUSHING 28350001211 导向套
SDLG G9190 G9220 WASHER 4015000168 垫圈GB97.1-12EpZn-300HV
SDLG G9190 G9220 BOLT 4011000197 螺栓GB5783-M12*25EpZn-8.8 GB5783-M12*25EpZn-8.8
SDLG G9190 G9220 SPLIT PIN 4016000308 开口销GB91-5*50EpZn-Q235A
SDLG G9190 G9220 NUT 4013000311 螺母GB6178-M24EpZn-10
SDLG G9190 G9220 WASHER 4015000167 垫圈GB97.1-24EpZn-300HV GB97.1-24EpZn-300HV
SDLG G9190 G9220 SCREW 28350001761 M24*129自制
SDLG G9190 G9220 Tilting cradle 28350001051 倾角支架总成
SDLG G9190 G9220 CYLINDER 4120004767 铲刀引出油缸90*50*1346-1794
SDLG G9190 G9220 PLATE 28350001581 右挡板
SDLG G9190 G9220 PLATE 28350001591 左挡板
SDLG G9190 G9220 NUT 4013000308 螺母GB6170-M30EpZn-10
SDLG G9190 G9220 NUT 4013000309 螺母GB6172.1-M30EpZn
SDLG G9190 G9220 SHIM 28350001701 垫片
SDLG G9190 G9220 SHIM 28350001711 垫片
SDLG G9190 G9220 SHIM 28350001721 垫片
SDLG G9190 G9220 PIN 28350002061 铜销
SDLG G9190 G9220 WEAR PART 28350001691 垫板
SDLG G9190 G9220 SHIM 28350001731 垫片
SDLG G9190 G9220 SHIM 28350001741 垫片
SDLG G9190 G9220 GUIDE PLATE 28350001681 导向板
SDLG G9190 G9220 WEAR PLATE 28350002101 垫板
SDLG G9190 G9220 SCREW 28350002051 铜螺钉
SDLG G9190 G9220 WEAR PART 28350001661 盖板
SDLG G9190 G9220 WASHER 4015000119 垫圈GB97.1-30EpZn-300HV GB97.1-30EpZn-300HV
SDLG G9190 G9220 WEAR PART 28350001651 盖板
SDLG G9190 G9220 SCREW 4011001061 螺栓GB5783-M27*100EpZn-10.9
SDLG G9190 G9220 NUT 4013000310 螺母GB6172.1-M27EpZn
SDLG G9190 G9220 BOLT 4011000750 螺栓GB5782-M30*200EpZn-10.9
SDLG G9190 G9220 WASHER 28350001751 垫圈
SDLG G9190 G9220 CLAMPING PLATE 28350001671 夹板
SDLG G9190 G9220 SHAFT 28350002131 齿轮驱动轴
SDLG G9190 G9220 NUT 4013000314 螺母GB889.1-M24EpZn-10
SDLG G9190 G9220 GEAR 28350002121 回转阀齿轮
SDLG G9190 G9220 NUT 28350002141 紧固螺母M42自制
SDLG G9190 G9220 WASHER 28350002151 垫圈
SDLG G9190 G9220 RETAINING RING 4015000130 挡圈GB894.1-25-65Mn GB894.1-25-65Mn
SDLG G9190 G9220 SHAFT 28350002111 传动轴
SDLG G9190 G9220 SLEEVE 28350002161 套筒
SDLG G9190 G9220 SCREW 4014000081 螺钉GB70.1-M12*45EpZn-8.8 GB70.1-M12*45EpZn-8.8
SDLG G9190 G9220 RETAINING RING 4015000272 P挡圈GB893.1-55-65Mn
SDLG G9190 G9220 RETAINING RING 4015000020 挡圈GB894.1-35-65Mn GB894.1-35-65Mn
SDLG G9190 G9220 SLEEVE 28350002251 轴套
SDLG G9190 G9220 TILTING CRADLE 28350001061 倾角支架
SDLG G9190 G9220 SHIM 28350001171 垫片
SDLG G9190 G9220 SHIM 28350001181 垫片
SDLG G9190 G9220 WEAR PLATE 28350001161 耐磨板
SDLG G9190 G9220 SCREW 4011001050 螺栓GB16674.1-M10*65EpZn-10.9
SDLG G9190 G9220 WEAR PART 28350001191 耐磨板
SDLG G9190 G9220 CLAMPING PLATE 28350001201 夹板
