LGMG CMT96A 2025 – Emergency steering electrical system – K2002-2720021712.S1A
Category: 2025 > CMT96A > C096AY3E0A008
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB862.2-10-65Mn | 4015010586 | 1 |
| 2 | Double sack wedge lock washer HF10 | 4190708409 | 1 |
| 3 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 1 |
| 4 | Emergency steering wire p35-8*8*4500-1.8 | 27200153121 | 1 |
| 5 | Emergency steering grounding wire p35-8*10*1500-1.8 | 27200153131 | 1 |
| 6 | Line | 27200140843 | 1 |
| 7 | Emergency steering rocker switch JK939C | 4130701384 | 1 |
| 8 | Holder | 27200142321 | 2 |
| 9 | Cable tie HS-J117 | 4130704969 | 2 |
| 10 | Bolt GB16674.1-M8*25flZnyc-8.8-480 | 4011010994 | 4 |
| 11 | Nut GB6177.1-M8flZnyc-8-480 | 4013010386 | 4 |
| 12 | Bolt GB16674.1-M10*50flZnyc-8.8-480 | 4011011219 | 1 |
