LGMG Road Sprinkler 2024 – Fuel tank assy – A0201-2702011236
Category: 2024 > Road Sprinkler > CMS50F > CS500W4E0A003
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Engine fuel filter | 4110702781 | 1 |
| 2 | Support | 27020106661 | 1 |
| 3 | PLATE | 2702010363-007 | 1 |
| 4 | Plate | 27020110001 | 6 |
| 5 | Bolt GB5783-M16*50EpZn-8.8 | 4011000269 | 4 |
| 6 | Bolt GB16674.1-M10*30EpZn-8.8 | 4011000475 | 16 |
| 7 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 24 |
| 8 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 6 |
| 9 | Cable tie HS-J117 | 4130704969 | 12 |
| 10 | Fuel hose LZB103-14*4300-P | 4049010235-004 | 1 |
| 11 | Iron fuel tank 530L LG02-RYX-04 | 4190707631 | 1 |
| 12 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 6 |
| 13 | Fuel tank bracket assy | 4110000118 | 3 |
| 14 | Nut GB6170-M16EpZn-8 | 4013000016 | 6 |
| 15 | Washer GB97.1-16EpZn-300HV | 4015000181 | 13 |
| 16 | Pin | 4110000120 | 3 |
| 17 | Pin GB91-3.2*22EpZn-Q235A | 4016000183 | 3 |
| 18 | Flap | 4110000122 | 6 |
| 19 | Backing plate | 27020101971 | 2 |
| 20 | String casing | 27140105021 | 4 |
| 21 | Cable tie 14400342 | 4130703098 | 5 |
| 22 | Flap | 4110000121 | 3 |
| 23 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 24 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 25 | Washer GB97.1-10EpZn-300HV | 4015000162 | 24 |
| 26 | pipe | 2702010577-005 | 1 |
| 27 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 1 |
| 28 | Bolt GB5783-M12*55EpZn-8.8 | 4011000254 | 2 |
| 29 | Bolt GB5782-M10*50EpZn-8.8 | 4011000048 | 1 |
| 30 | Bolt GB5782-M16*60EpZn-8.8 | 4011000068 | 1 |
| 31 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 2 |
| 32 | Bolt GB16674.1-M10*40EpZn-8.8 | 4011000163 | 1 |
| 33 | Cable tie assy | 4110000119 | 3 |
| 34 | Bolt GB16674.1-M10*25EpZn-8.8 | 4011000474 | 2 |
| 35 | Bolt GB5786-M14*1.5*25flZnyc-12.9-480 | 4011010772 | 1 |
| 36 | Washer GB96.1-14flZnyc-300HV-480 | 4015010371 | 1 |
| 37 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 4 |
| 38 | Washer GB97.1-8EpZn-300HV | 4015000072 | 2 |
| 39 | Holder | 27200142321 | 2 |
| 40 | Plate | 27010113352 | 5 |
| 41 | L part 139*30*77 | 27200149691 | 1 |
| 42 | Hose clamp JB8870-D20 | 4017000010 | 6 |
| 43 | Bolt GB5782-M16*80EpZn-10.9 | 4011000438 | 2 |
| 44 | Bolt GB5782-M16*70EpZn-10.9 | 4011000824 | 4 |
